ESC/P-K Emulation
445
Appendix
15
Form overlay 64 Constantly performs Form Overlay by selecting a form name (No. 01-64)
registered on the machine.
[0] (Default) : Off
[1-64] : No. 1 - No. 64
Important•Since this setting selects the default value, it is not affected when an
extended commend is received.
•Once a form name is selected, it will remain displayed even if the
form is deleted. When a form name is selected using the up and
down arrow keys, it will not be displayed. In this case, the setting is
set to "Off".
Stapling 66 Sets the stapling position.
[0] (Default) : Off
[1] : Top left
[2] : Top Double
[3] : Top Right
[4] : Left Double
[5] : Right Double
[6] : Bottom Left
[7] : Bottom Double
[8] : Bottom Right
Bypass Tray -
Wait User
67 Sets whether to suspend the print processing when feeding paper from
Bypass Tray. The processing is resumed by a user operation on the
machine.
[0] : Off
[1] (Default) : On
Punching 69 Select the position for punching.
[0] (Default) : Off
[1] : Top
[2] : Bottom
[3] : Left
[4] : Right
Number of holes 70 Select the number of punch holes.
[0] (Default) : 2 holes
[1] : 3 holes
Binary character
strings
72 Sets the specified character strings when entering commands in
hexadecimal format.
[0] (Default) : Off
[1] : &$%$
[2] : $?!#
0 Style 73 Sets the typeface for "0".
[0] (Default) : 0
[1] :
Number of sets 74 Sets which value to use as the number of print sets.
[0] : Protocol
[1] : Panel
[2] (Default) : Command
Setting Item
Item
Number
Value
