Replacing Consumables
47
Maintenance
3
Replacing the Staple Cartridge (for Booklet Maker Unit for Finisher-B1)
When the Booklet Maker Unit for Finisher-B1 (optional) is installed and it is time to
replace the staple cartridge, a message appears on the touch screen. When this
message appears, load a new staple case into the staple cartridge.
Important • The use of staple cartridges not recommended by Fuji Xerox may impair quality and
performance. Use only staple cartridges recommended by Fuji Xerox for the machine.
Note • To order a staple cartridge, contact our Customer Support Center.
1
Make sure that the machine is not
operating, and open the side cover
of the finisher.
2
Hold the tabs on both sides of the
staple cartridge and pull the
cartridge out of the finisher.
3
Hold the tabs on both sides of a
new staple cartridge, and insert it
into the original position until it
clicks.
Note • If you have trouble inserting
the cartridge, make sure that
the staples in the cartridge are
properly in place.
4
Repeat steps 2 and 3 to replace
the other staple cartridge.
5
Close the side cover of the finisher.
Note • If the side cover of the finisher is not completely closed, a message will appear and the
machine will not operate.
Emptying the Punch Waste Container (for Finisher-B1)
When the hole punch waste container becomes full, a message appears on the touch
screen. When the message is displayed, empty the hole punch waste container as
instructed.
Make sure to discard all paper chads when emptying the hole punch waste container.
If you do not empty the container completely, the container becomes full before the
message stating to empty the container appears again, and this can cause a
breakdown of the machine.
