3 Maintenance
70
Maintenance
3
3 Hold the tabs on both sides of a new staple
cartridge, and insert it into the original
position until it clicks.
4 Repeat steps 2 and 3 to replace the other staple cartridge.
5 Close the finisher side cover.
Note • If the finisher side cover is not completely closed, a message will appear and the machine
will remain paused.
Replacing Booklet Staple Cartridge (for Finisher-C1 with Booklet Maker)
When the Finisher-C1 with Booklet Maker (optional) is installed and the booklet staple
cartridge needs to be replaced, a message appears on the touch screen. When this
message appears, load a new staple case into the booklet staple cartridge.
Important • The use of staple cartridges not recommended by Fuji Xerox may degrade quality and
performance. Use only booklet staple cartridges recommended by Fuji Xerox.
Note • To order a booklet staple cartridge, contact our Customer Support Center.
1 Make sure that the machine is not operating,
and open the finisher front door.
2 While pressing the handle [R2] and handle
[R3] to the right (1), pull the booklet staple
cartridge unit out of the finisher (2).
3 Hold the tabs on both sides of a new booklet
staple cartridge.
R2
R3
