Printing Basics
150
Automatic Document Feeder (ADF) Guidelines
(DocuPrint M215 fw Only)
The ADF accommodates the following original sizes:
• Width: 148–215.9 mm (5.83–8.50 inches)
• Length: 210–355.6 mm (8.27–14.00 inches)
The weight range includes 60–105 gsm.
Follow these guidelines when loading original documents into the ADF:
• Load documents face up so that the top of the document enters the printer first.
• Place only loose sheets of paper in the ADF.
• Adjust the document guides so that they fit against the documents.
• Insert paper in the document feeder tray only when the ink on the paper is completely dry.
• Do not load documents above the MAX fill line. You can load up to 15 sheets of 64 gsm
documents.
NOTE:
• You cannot load the following documents in the ADF. Be sure to place them on the document glass.
Curled originals Pre-punched paper
Lightweight originals Folded, creased or torn originals
Cut and paste originals Carbon paper
