FUTABA 7PX User Manual

When the mode is activated by a switch, indicated
on the home screen for a few seconds.
Home screen
Menu screen
Menu-2
Menu-1
Mixing menu
4WS mixing
Display the current 4WS type.
113
Function
4WS Mixing
4WS Mixing
This function can be used with crawlers and other 4WS type vehicles. It is mixing that uses
the 1st channel to control front side steering and the auxiliary channel to control rear side
steering.
A method of specifying directly for each type of opposite phase (only on the in-phase
side), reverse phase, in-phase side and rear side by selecting PS1, PS2, PS4, PS5, PS6 in the
"
Switch select
"
function (page 69). And, it is possible to switch in order.
The mixing function is assigned to auxiliary channels used by other mixing cannot be
used. When the number of channels is insuf cient, cancel the other mixing.
(Preparation)
- Since this function is used by switching the type of 4WS with a switch, the switch used by the
switch select function (page 69) is set.
4WS mixing adjustment
1
(Function ON/OFF)
Tap "Mixing" (ON) or (OFF) to select ON /
OFF.
"OFF" :Mixing function OFF
"ON" :Mixing function ON
Setting
- Tap (ON) / (OFF).
1M23N32602_7PX_E.indb 113 2017/08/02 14:17:31

FUTABA 7PX Specifications

General

Channels	7
Frequency	2.4GHz
Telemetry	Yes
Data Logging	Yes
Model Memory	40 models
Compatibility	T-FHSS, S-FHSS
System	T-FHSS
Display	4.3 inch color TFT LCD touch screen
