FUTABA 7PX User Manual

Home screen
Menu screen
Menu-2
Menu-1
Linkage menu
Channel Reverse
For S-FHSS (analog) system, 5 to
7 channels are displayed on the
2nd page.
Tap to change page.
54
Function
Sub trim
90deg
Use this function to adjust the neutral position of the steering, throttle, channel 3 and
channel 4 servos.
(Preparation)
- Follow the instructions of the model, install the servo horn and
make the next adjustment.
- Set the steering and throttle digital trims to the neutral "0" posi-
tion. Set auxiliary channels to the center "0" position.
- Tap the trim display part of the channel you want to adjust.
Value input buttons appear on the Sub-trim menu screen.
1
(Sub trim adjustment)
Use the [+] or [-] button to adjust the center.
(Each channel can be set similarly.)
Sub trim adjustment
Use to adjust the neutral position
*Sub trim adjusts the entire range of
the servo in the set direction.
Sub trim
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Sub trim
-100~+100
Initial value : 0
2
When fi nished, return to the Linkage menu screen by pressing the HOME button.
1M23N32602_7PX_E.indb 54 2017/08/02 14:17:16

FUTABA 7PX Specifications

General

Channels	7
Frequency	2.4GHz
Telemetry	Yes
Data Logging	Yes
Model Memory	40 models
Compatibility	T-FHSS, S-FHSS
System	T-FHSS
Display	4.3 inch color TFT LCD touch screen
