FUTABA 7PX User Manual

Home screen
Menu screen
Menu-2
Menu-1
Linkage menu
Servo view
For S-FHSS (analog) system,
1 to 7 channels are displayed.
64
Function
Servo view
Servo operation of each channel can be checked. Operation of the steering angle adjust-
ment, when a mixing function was set, etc. can be easily checked.
Servo view
1
Operating each channel, such as a steering wheel or throttle trigger, the graph works and
the servo operation can be confi rmed.
2
When fi nished, return to the Linkage menu screen by pressing the HOME button.
Confi rm operation
1M23N32602_7PX_E.indb 64 2017/08/02 14:17:19

FUTABA 7PX Specifications

General

Channels	7
Frequency	2.4GHz
Telemetry	Yes
Data Logging	Yes
Model Memory	40 models
Compatibility	T-FHSS, S-FHSS
System	T-FHSS
Display	4.3 inch color TFT LCD touch screen
