FUTABA 7PX User Manual

187
Reference
Caution
Reference
Specifications
Transmitter T7PX
Wheel system, 7 channels (4 channels except the S-FHSS system.)
- Transmitting frequencies 2.4GHz band /- Transmitting RF power output: 100mW EIRP
- Futaba T-FHSS SR/T-FHSS/S-FHSS/FASST-C2
- Power requirement
(Ni-MH battery) NT5F1800B Ni-MH battery (6V)
(LiFe battery) FT2F1700BV2 (6.6V)
- Current drain 350mA or less (When the T-FHSS, Vibration off, back lighting on)
- Transmitting antenna 1/2λdipole
- 4.3 inch backlighted color TFT liquid crystal touch panel.
*When you turn on your 7PX, bright dots may appear on your screen display. Your display contains an extremely large num-
ber of TFT and is manufactured using high-precision technology. Any bright dots that may appear on your display are intrin-
sic of the TFT manufacturing technology.
Receiver R334SBS / : (T-FHSS SR /T-FHSS system, 4 channels)
- Receiving frequency: 2.4GHz band /- Telemetry Receiver RF power output: 10mW EIRP
- Power requirement: 3.7V~7.4V battery (Dry cell battery cannot be used.)
- System: S-FHSS SR/T-FHSS system (auto detection) /S.BUS2 system
- Size: 1.34x0.88x0.45
"
(33.9x22.3x11.3mm) (excluding a projection part) /- Weight :0.23oz. (7.5g)
*Specications and ratings are subject to change without prior notice.
T-FHSS SR
T-FHSS
S-FHSS
FASST
SR mode channel: ON
SR mode channel: OFF
- SR mode of Futaba SR compatible servo.
-
Normal mode of Futaba SR compatible servo.
-
Futaba digital servo.
-
Normal mode of Futaba SR compatible servo.
-
Futaba digital servo.
- Futaba all servo.
(Normal mode of Futaba SR compatible servo.)
-
Normal mode of Futaba SR compatible servo.
-
Futaba digital servo.
- Futaba all servo.
(Normal mode of Futaba SR compatible servo.)
-
Normal mode of Futaba SR compatible servo.
-
Futaba digital servo.
- Futaba all servo.
(Normal mode of Futaba SR compatible servo.)
Digital servo
Analog servo
Digital servo
Analog servo
Digital servo
Analog servo
System
Response / SR node Usable servos
Be sure to use the T7PX receiver setting and the servo to be used under predetermined conditions.
Under other conditions, the set will not operate, or the specified performance will not be displayed even if it operates. In addition, it
may cause servo trouble. Futaba will not be responsible for damage, etc. caused by combination with the products of other companies.
Receiver’s battery:Matched to the ratings of the receiver and connected servo (dry cell battery cannot be
used).
In addition, the FSU Fail Safe Unit cannot be used because the system is different. Use the fail safe function
of the transmitter.
1M23N32602_7PX_E.indb 187 2017/08/02 14:17:49

FUTABA 7PX Specifications

General

Channels	7
Frequency	2.4GHz
Telemetry	Yes
Data Logging	Yes
Model Memory	40 models
Compatibility	T-FHSS, S-FHSS
System	T-FHSS
Display	4.3 inch color TFT LCD touch screen
