FUTABA 7PX User Manual

Home screen
Menu screen System menu screen
LED Setting
183
Function
LED Setting
You can adjust the brightness and lighting method of the pilot LED light.
The pilot LED lighting method can be selected from
"
always on
"
,
"
off
"
or
"
interlock
with backlight
"
.
LED Setting
1
(Setting pilot LED)
Tap the [Pilot LED], a list of lighting mode will be displayed on the screen. tap the lighting
mode you want to use from the list.
LED setting
2
(Setting Pilot LED brightness)
Tap the value button of the [Brightness]. Value input buttons
appear on the screen and use the [+] and [-] buttons to ad-
just the pilot LED brightness amount.
3
When finished, return to the System menu screen by pressing the HOME button.
Pilot LED mode
Backlight, Always On, OFF
Adjust button
Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Brightness
0~20
Initial value : 20
1M23N32602_7PX_E.indb 183 2017/08/02 14:17:48

FUTABA 7PX Specifications

General

Channels	7
Frequency	2.4GHz
Telemetry	Yes
Data Logging	Yes
Model Memory	40 models
Compatibility	T-FHSS, S-FHSS
System	T-FHSS
Display	4.3 inch color TFT LCD touch screen
