Alarm button, see page 3:19.
Air Detector button, see page 3:19.
Blood Pump button, see page 3:20.
Blood Pump Up/Down keys, see page 3:20.
Keypad, see page 3:20.
The Information Display, which is connected to these buttons, is
described on page 3:22.
The Keypad consists of the Cursor keys,theDisplay Up/Down keys,
the Select key and the Back key. See below for page references for
each key.
Right/Left Cursor keys, see page 3:21.
Display Up/Down keys, see page 3:21.
Select key, see page 3:20.
Back key, see page 3:21.
HCEN12239 Revision 12.2010
Program version 3.xx
AK 96
®
Operator's Manual - Operating the Machine
3:9
