SECTION 1 SYSTEM OVERVIEW
The G950 Integrated Flight Deck System presents flight instrumentation, position, navigation, communication,
and identification information to the pilot using flat-panel color displays. The system is distributed across the
following Line Replaceable Units (LRUs):
•
GDU 1040
Primary Flight Display (PFD)
•
GDU 1040
Multi Function Display (MFD)
•
GMA 347
Audio Panel with Integrated Marker Beacon
Receiver
•
GIA 63W
Integrated Avionics Units (IAU)
•
GDC 74A
Air Data Computer (ADC)
•
GTX 33
Mode S Transponder
•
GRS 77
Attitude and Heading Reference System
(AHRS)
•
GMU 44
Magnetometer
Figure 1-1 shows interactions between the LRUs. Additional/optional equipment are shown in Figure 1-2. The
G950 is capable of interfacing with the following optional equipment:
•
GTX 33 ES
Mode S Transponder
•
GWX 68/70
Weather Radar
• S-TEC 55X Autopilot
•
KTA 870
Traffic System
•
WX 500
Lightning Detection System
