Garmin G950 Pilot’s Guide for the Pilatus PC-6
190-00870-02 Rev. A
358
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
ALTITUDE DISPLAY
The Pilot can select the volume of airspace in which traffic is displayed. Traffic Advisories (TAs) outside of
these limits will still be shown. Refer to the KTA 870 Pilot’s Guide for specific display thresholds.
Changing the altitude display mode:
1) On the Traffic Page, press the ALT MODE Softkey.
2) Press one of the following Softkeys:
• BELOW
• NORMAL
• ABOVE
• UNREST (unrestricted)
3) To return to the Traffic Page, press the BACK Softkey.
Or:
1) Press the MENU Key.
2) Turn the small FMS Knob to select one of the following:
• BELOW
• NORMAL
• ABOVE
• UNREST (unrestricted)
3) Press the ENT Softkey.
TRAFFIC MAP PAGE DISPLAY RANGE
The display range on the Traffic Map Page can be changed at any time. Map range is adjustable with the
Joystick from 2 to 40 nm, as indicated by the map range rings.
Changing the display range on the Traffic Page:
1) Turn the Joystick.
2) The following range options are available:
• 2 nm
• 2 and 6 nm
• 6 and 12 nm
• 12 and 24 nm
• 24 and 40 nm
