SECTION 3 ENGINE INDICATION SYSTEM
The G950
®
Engine Indication System (EIS) displays critical engine, electrical, fuel, and other system parameters
on the left side of the MFD during normal operations (Figure 3-1).
Figure 3-1 Multi Function Display (Normal Operations)
EIS Display
Green bands on the instruments indicate normal ranges of operation; yellow and red bands indicate caution
and warning, respectively. When unsafe operating conditions occur, the corresponding readouts flash to indicate
cautions and warnings. If sensory data to an instrument becomes invalid or unavailable, a red “X” is displayed
across the instrument.
