190-00870-02 Rev. A
Garmin G950 Pilot’s Guide for the Pilatus PC-6
351
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
Muting the “TIS Not Available” voice alert:
1) Select the Traffic Map Page.
2) Press the
TNA MUTE
Softkey. The status is displayed in the upper left corner of the Traffic Map Page.
Or:
a) Press the
MENU
Key.
b) Select ‘‘’Not Available” Mute On’ (shown if TNA muting is currently off) and press the ENT Key.
SYSTEM STATUS
The G950 performs an automatic test of TIS during power-up. If TIS passes the test, TIS enters Standby Mode
(on the ground) or Operating Mode (in the air). If TIS fails the power up test, an annunciation is shown in the
center of the Traffic Map Page.
Traffic Map Page Center
Banner Annunciation
Description
NO DATA Data is not being received from the transponder*
DATA FAILED
Data is being received from the transponder, but a failure is
detected in the data stream*
FAILED The transponder has failed*
UNAVAILABLE TIS is unavailable or out of range
* Contact a service center or Garmin dealer for corrective action
Table 6-18 TIS Failure Annunciations
Figure 6-71 TIS Power-up Test Failure
Data Not
Received from
Transponder
System Test has
Failed
