System description
2-1
2 System description
Principles of functions
The B30 monitor is a modular multiparameter patient monitor. The monitor is especially
designed for monitoring in PACU, ED, Wards, Step down units, ICU, CCU and OR in regions
where anesthesia gas monitoring is not required. It can also be used during transportation
within the hospital.
The modular design makes the system flexible and easy to upgrade.
System introduction
The B30 monitor system may consist of the elements shown below.
NOTE: Your system may not include all these components. Consult your local
representative for the available components.
Figure 2-1 B30 patient monitor system
(1) B30 with module(s)
(2) Printer (network printer only)
(3) Other monitors in the network. NOTE: You cannot view other monitors on the B30 with L-
DICU08 software.
NOTE: The allowed cables, batteries, transducers and accessories for the monitor are
listed in the “Supplies and Accessories” catalog delivered with the monitor.
WARNING If you accidentally drop the monitor, modules or frames, have them
checked by authorized service personnel prior to clinical use.
WARNING Connect only one patient to the monitor at a time.
WARNING Do not use the monitor without manufacturer approved mounting
attached.
