PRODUCT OR
COMPONENT
NET WEIGHT
KG (LBS)
DIMENSIONS MM (INCHES)
LOAD BEAR‐
ING AREA
MM (INCHES)
WEIGHT/ OC‐
CUPIED
AREA
MOUNTING METHOD
WIDTH
DEPTH
HEIGHT
EMI Filter enclosure
US (4)
31 (68)
406 (16)
180 (7)
965 (38)
Wall-mounted
EMI Filter enclosure
CE (4)
<40
300
210
950
Wall-mounted
DL keypad
1.4 (3)
283 (11.55)
300 (11.8)
82 (3.25)
DL LCD monitor
8.2 (18)
179 (7)
387 (15.2)
504 (19.8)
VCIM
0.95 (2.09)
450 (17.7)
150 (5.9)
50 (2)
Videostation VCR
12 (26.5)
370 (14.57)
270 (10.63)
144 (5.67)
Components common to IVUS Rev 1 & Rev 2 Option
PIM (Ultrasound
probe)
2 (4.4)
38
96
177
Control Station
4 (8.8)
120
360
240
Joystick
1 (2.2)
90
76
102
Isolation transform‐
er
7 (15.4)
97
267
171
IVUS CPU
15 (33.1)
396
162
510
IVUS Keyb. &
mouse pad
1 (2.2)
NA
NA
NA
IVUS monitor
15 (33.1)
420
432
240
Image printer
6 (13.2)
158
184
18
4-way Video Switch
1 (2.2)
44
222
241
Components specific to IVUS Rev 2 Option
PIMr
1,5 (3,2)
356
102
102
Pimette
1 (2,2)
142
76
18
Touchpad controller
1 (2,2)
211
180
76
Printer HP
1,3 (2,8)
227
138
117
NOTE: (1) including patient weight.
NOTE: (2) Depth.
NOTE: (3) Maximum dimensions given. Exact dimensions depend on chiller manufacturer
type.
NOTE: (4) Recommended supplier.
2.2 Positioner and Table Floor Mounting
The distances between the Innova LC Positioner and the Tables are critical for a proper clinical
usage. For this reason, GEMS provides two floor mounting templates to ensure these components
are properly placed in relation to one another.
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
140 2 Mounting Requirements
