GE Innova 4100 User Manual

2.2 Equipment Heat Output (Dissipation)
2.2.1 Equipment Heat Output tables
Refer to Table 3-3. To obtain heat output information for components not specified in Table 3-3,
refer to the appropriate component Pre–Installation Manual listed in Chapter 2, Section 3, Basic
Innova System Compatibility.
Table 3-3:
HEAT OUTPUT
Stand by Moderate Use (4) Typical Use (4) Maximum Use (4)
Room Core System kW BTU/hr kW BTU/hr kW BTU/hr kW BTU/hr
Exam
Room
Innova LC positioner and
table
0.41 1394 0.55 1858 0.89 3020 1.62 5517
Ctrl Room
DL user area with 1 TFT
monitor
0.16 546 0.16 546 0.16 546 0.16 546
2 B&W flat monitors 0.17 573 0.17 573 0.17 573 0.17 573
Tech
Room
C1 Cabinet 0.41 1398 0.69 2366 0.99 3389 1.29 4412
C2 Cabinet 0.29 989 0.33 1125 0.54 1828 0.87 2966
Coolix X-Ray tube chiller
(1) (2)
2.53 8619 4.49 15309 5.49 18725 6.93 23625
Detector conditioner 0.21 709 0.21 709 0.21 709 0.21 709
Main disconnect panel -
PDB
0.4 1534 0.45 1534 0.45 1534 0.45 1534
Total for core system 4.6 15762 7.0 24020 8.9 30324 11.7 39881
Room Options (3 & 5) Stand by Moderate Use (4) Typical Use (4) Maximum Use (4)
Exam
Room
3 in room B&W TFT moni‐
tors
0.25 859
Same values as Stand
by
Same values as Stand
by
Same values as Stand
by
In room AW TFT monitor 0.12 409
Typical injector 0.09 320
Ctrl Room
AW work station 0.35 1201
2 AW TFT monitors 0.24 818
Printer 0.31 1054
Typical configuration without fluoro
UPS
5.9 20424 8.4 28682 10.3 34985 13.1 44543
NOTE:
(1) Air flow requirements 1200 m
3
/h (706 CFM)
NOTE: (2) For more details, consult appropriate pre–installation manual
NOTE:
(3) For UPS 20 kVA option refer to
Section 2.2.2
NOTE: (4)
Moderate use: 8 cases / 10 hours, typical use: 11 cases / 10 hours, maximum
use: during case.
NOTE: (5) For IVUS enviromental limatations and heat output, refer to
Section 2.2.3
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
56 2 Environmental Requirements/Limitations
