2.3.3.3 2286398 – On grade, Floor anchor
Table 5-10:
Item Name Part # Description Quan. Notes
Floor Anchor 46-302265P1 Floor Anchor Bolt; 5/8-10 x 6 in.
12 anchors for LC Positioner and
4 anchors for Table
16 pc On Grade anchor mounting
method hardware
Grout assy 2285055 - 10 kg Powdered Mortar Ardex
K-15
- RTV Silicon Rubber Adhesive
- 18 mm making tape adhesive
- Open cell foam
1 kit Used in constructing LC Po‐
sitioner grout dam
Dowel 2290937-2 Wood Dowel; 16 mm diameter 12 pc
Cable Con‐
duit
2285057 Cable conduit - sheet metal part 1 pc
Vinyl Trim 2296890 Gripping Range; 1.5 to 3 mm THK 1 m
Vinyl Trim 2296891 Vinyl trim with segmented metal
core 12 mm
1 m
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
Chapter 5 Physical Characteristics 157
