2 Tools and Test Equipment
Refer to Table 7-2. To obtain a list of tools and test equipment for components not specified in
Table 7-2, refer to the appropriate component Pre-Installation Manual listed in Chapter 2, Section
3, Basic Innova System Compatibility.
Table 7-2:
PRODUCT OR COMPO‐
NENT
TOOL OR TEST EQUIP‐
MENT
USED FOR
SOURCE
RECEIVED (DATE)
Innova LC Positioner
Service Engineer's Tool
Case
General Use
Level, Protractor Type
Positioner Checks
Plumb Line included in
46-216640G1
Positioner Checks
Torque Wrench 2 to 20
daN.m (15 ft. lbs. to 150 ft.
lbs.)
Positioner Checks
1/2 inch Ratchet Wrench
(2)
Raise and Lower Posi‐
tioner shipping dolly
Wrench, Spanner
(46-176584P1)
High Voltage Cable Instal‐
lation
Laptop Computer (MS-
DOS Windows)
Positioner Configura-tion
and Calibration
Status Display
Same as for Innova LC (Service Engineer's Tool Case)
Omega/Innova
IQ
Table
Same as for Innova LC (Service Engineer's Tool Case) Fill in any additional tools or test equipment as
required
Installation dolly (PN
5265134)
Replacing Omega with In‐
nova
IQ
Table
C2 Cabinet
Same as for Innova LC (Service Engineer's Tool Case) Fill in any additional tools or test equipment as
required
X-Ray Head
Same as for Innova LC (Service Engineer's Tool Case) Fill in any additional tools or test equipment as
required
C1 Cabinet
Same as for Innova LC (Service Engineer's Tool Case) Fill in any additional tools or test equipment as
required
Same as for Innova LC (Service Engineer's Tool Case) Fill in any additional tools or test equipment as
required
Ethernet adaptation kit for
laptop 2128794
General use (to be or‐
dered before delivery of
system)
DL User parts
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
244 2 Tools and Test Equipment
