GE Innova 4100 User Manual

•
C2 cabinet positioner control,
•
Fluoro UPS interface box near C1 cabinet (Fluoro UPS option),
•
VCIM console,
•
Revolution Digital Detector mounted on Innova LC positioner:
•
An external Digital Detector chiller is mandatory.
•
53 cm (21”) Hi–Brite monitor,
•
43 cm (17”) Hi–Brite monitor (optional).
•
LCD NEC 19” 1990 SXi Color Monitor.
•
LCD 18” EIZO GmbH (formerly Siemens) SMD 18101G or 18102G B & W Monitor.
•
LCD 19” EIZO GmbH SMD 19100G Color Monitor.
•
LCD 19” GmbH SMD 19100G B & W Monitor.
1.6 Description of the image monitors suspensions
The common type of this suspension is an XT inboard monitor bridge.
A monitor frame support receiving 3 monitors (1 life monitor, 1 reference monitor, 1 Advantage
Windows monitor).
A monitor frame support receiving 4 monitors (1 life monitor, 1 reference monitor, 1 Advantage
Windows monitor (optional for Innova 2100–IQ), 1 ECG monitor).
A monitor frame support receiving 3, 4, or 6 LCD monitors (fixed monitor suspension).
Only for Control Area a Gyro TV® wall mount can supports the 2 Hi–Brite monitors 53 cm or 43
cm (21” or 17”).
1.7 Description of the DL and associated devices
An Innova System uses the DL Digital Imaging system.
•
The C1 Cabinet contains:
1.
DL Computer,
2.
Modem (option)
3.
Firewall
4.
Ethernet switch
5. KVM–local
6. Video Splitter
•
The user area is made of:
1.
I/R Receiver / Emitter
2.
DL color LCD monitor (19”)
3.
Keyboard,
4.
Mouse
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
Chapter 2 Innova Systems 31
