18.4.5 Run the cables for extra monitors
NOTE:
Depending on local regulations, it can be required to put power cables in dedicated
ducts.
1. Extra monitors located in patient room are delivered with three cables: video cable, ground
cable and power cable. These cables are 24 meters standard length. The cables can be
extended using same option as monitor suspension uses.
18.4.6 Run the cable Set Group 3
Group 3 links the components of the technical room.
NOTE: Depending on local regulations, it can be required to put power cables in dedicated
ducts.
1. The cable set is delivered in the box, each cable is individual:
•
C1 cabinet and C2 cabinet shall be close to each other, length reference is C1 entrance.
•
Chiller and conditioner shall be at 12 meters maximum from their control subsystem.
•
Use the cable rings to run the different cables on subsystems in conformity with the
subsystem color coded (See this procedures
Required Conditions ).
•
Set of cables includes:
○
2 cables between Jedi and Chiller.
○
3 cables between C1 and C2 cabinets.
○
6 cables between C2 and C1 cabinets.
○
2 cables between C1 cabinet and conditioner.
○
2 cables between C1 cabinet and Phone plug / PDB.
18.4.7 Routing of the Acquisition cable for Mac/lab
1. The Mac/lab acquisition cable #417335–003 is delivered as part of the pre installation kit of
Innova.
2. This 70 foot cable shall be routed in the cable channel between the control room and the table
foot.
18.5 Finalization
No finalization steps.
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
Chapter 6 Electrical Connections 221
