Battery safety instructions:
•
The battery–voltage is dangerous for person’s safety.
•
Never dispose of battery in a fire: They may explode.
•
Do not open or mutilate battery: Their contents (electrolyte) may be extremely
toxic.
If exposed to electrolyte, wash immediately with plenty of water.
•
Avoid charging in a sealed container.
1.13 Intravascular Ultrasound (IVUS) Option
1.13.1 Purpose
Volcano is a manufacturer of intravascular ultrasound systems, which are used in the cath lab. GE
has a strategic agreement with Volcano. GE will be selling and servicing some of the Volcano
products.
1.13.2 Product Description
The Volcano IVUS s5i and s5i/GE systems are dedicated equipments for IntraVascular UltraSound
imaging, designed as add on equipment to Vascular Imaging systems. The IVUS s5i/GE
equipment is also capable of recieving patient data from the Innova system.
The Volcano IVUS rev 1 Hardware configuration consists of:
•
A computer (IVUS CPU) connected to a monitor (IVUS Monitor), both located in the Control
Room,
•
A Patient Interface Module (IVUS PIM) located in the Procedures Room
•
Various user interface units to control the system
○
IVUS Control Station,
○
IVUS Joystick,
○
IVUS Keyboard & mouse pad installed in the Control Room,
•
Optional Image Printer, located in the Control Room is available for the IVUS system
The IVUS integration to Innova, involves further components :
•
Innova Central (Touchscreen) as optional control station,
•
Video Signal Switch to route Workstation and IVUS video signals,
•
Procedures Room monitor shared by Workstation (AW or Ca1000) and IVUS operations,
•
Network cable (IVUS to Innova system),
•
Grounding cable (IVUS CPU to Patient Table ground bar),
The s5i/GE rev 1 is used with phased array catheter provided by Volcano (Eagle Eye Gold
catheter).
The s5i/GE rev 2 includes a new PIM for rotational catheter and another one for FFR capabilities.
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
Chapter 2 Innova Systems 35
