4 Functional Requirements
4.1 Electrical Requirements
Innova System require two specific power lines, two three phase for C1 cabinet (see Illustration
AC Interconnect without Fluoro UPS
in Chapter 6, Section 1, Power Distribution).
Connect the main power demand to the X–Ray generator – Jedi (C1 cabinet).
X–Ray generator is feed by a 126 kVA three phase power line.
For Generator Power Supply Features, see ref 60601.1 IEC.
NOTE:
In CE configuration, C2 cabinet is fed by C1 cabinet.
Table 3-14: ELECTRICAL REQUIREMENTS: System line voltage without Fluoro UPS
Peak Max Power
input (kVA)
Frequency (Hz)
Mains Voltage (V)
Max. Line Impe‐
dance (ohms)
Peak Current (A)
Average Current
(A)
Mains Wire
150
50 or 60
380 to 480 (3 ph, ±
10%)
0.09 to 0.12
228 to 180 for C1
16 to 13
4 wires (3 ph +
GND).
Table 3-15: ELECTRICAL REQUIREMENTS: System line voltage with Fluoro UPS UL
Peak Max Power
input (kVA)
Frequency (Hz)
Mains Voltage (V)
Max. Line Impe‐
dance (ohms)
Peak Current (A)
Average Current
(A)
Mains Wire
150
60
480 (3 ph + N,
±10% )
0.09 to 0.12
180 for C1
13
5 wires (3 ph + N
+ GND)
Table 3-16: ELECTRICAL REQUIREMENTS: System line voltage with Fluoro UPS CE
Peak Max Power
input (kVA)
Frequency (Hz)
Mains Voltage (V)
Max. Line Impe‐
dance (ohms)
Peak Current (A)
Average Current
(A)
Mains Wire
150
50 or 60
380/400/415 (3 ph
+ N, ±10% )
0.09 to 0.12
228 for C1
16
5 wires (3 ph + N
+ GND)
NOTE:
PDB (CE) maximum rating is equal to 57 kVA.
PDB (UL) maximum rating is equal to 124 kVA.
Line impedance should be compliant with IEC 601.2.7 Refer to the table
Max Line
Impedance for feeder line between Generator cabinet and Hospital
in Chapter 6,
Section 4, Power and Grounding Requirements.
When a Fluoro UPS is or will be installed, a Neutral line is mandatory. An IT or Delta
configuration power input requires the installation of an isolation transformer (see
transformer specification below)..
For C2 Cabinet there are two positions for the shunts:
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
Chapter 3 Physical Requirements of Room 79
