18.4.2 Run the cable Set Group 1
1.
Unroll the cable set from the spool and lie it down between gantry and technical area (power
cables are not linked to the cable set).
2. Unpack carefully and lie down the free cables of group 1 (optical fiber, water pipes).
3. Add a
pulling wire
to the cable or cable set to be placed in the duct.
4. Pull an other
pulling wire
through the duct between technical area and gantry.
5. Link the cable or cable set to the
pulling wire
.
6. Pull the
pulling wire
out of the appropriate duct sliding the cable set through the duct.
7. Adjust cable position at gantry and table level.
8. Unlink cable set and
pulling wire
.
NOTE: Depending on local regulations, it can be required to put water pipes and power
cables in dedicated ducts.
NOTE: The power cable detector between Omega V and LC (mischart 27722A) is not part
of spool but part of group 1.
18.4.3 Run the cable Set Group 2
1. Unroll the cable set from the spool and lie it down between control booth and technical area
(power cables are not linked to the cable set).
2. Add a
pulling wire
to the cable or cable set to be placed in the duct.
3. Pull an other
pulling wire
through the duct between technical area and control booth.
4. Link to the
pulling wire
the cable or cable set to be placed in the duct.
5. Pull the
pulling wire
out of the appropriate duct sliding the cable set through the duct.
6. Adjust cable position in the control booth.
7. Unlink cable set and
pulling wire
.
8.
Power strip and KVM support have to be attached on the wall.
9.
The power strip delivers two powers:
•
UPS type: Flat panel, KVM, one free.
•
Non UPS type: External CD, Live monitor, roadmap monitor, two free.
NOTE:
Depending on local regulations, it can be required to put power cables in dedicated
ducts.
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
Chapter 6 Electrical Connections 219
To Next Page
