Table 3-13: D distance
ANGIO CARDIO NEURO
Omega IV Compact NA 1395 mm (54.9 in) NA
Omega V Long 1278 mm (50.3 in) NA 1395 mm (54,9 in)
Omega V non motorized Long 1278 mm (50.3 in) NA 1395 mm (54,9 in)
Innova
IQ
Table
1278 mm (50.3 in) NA 1395 mm (54,9 in)*
NOTE:
* in case of a Innova
IQ
Table upgrade, there is the possibility of a distance of 1595 mm
(62.8 in).
Due to the plastic bushing used in the USA to protect cables from the sharp edges
of conduits it is necessary to place the cable conduit inside the table cable access
opening but the height of the outcoming conduit plus bushing is limited to 1/2 in
(12.7 mm).
NOTE: Refer to table
Chemical anchors Pull out efforts and recommendations in Chapter 5,
Section 2, Mounting Requirements for pull out effort on each fixation bolts.
3.3.5 Water Pipe Requirements
•
An Innova LC System uses a Performix 160 A X–Ray tube with a recirculating chiller.
•
Two water hoses are supplied to allow water circulation between Innova LC Positioner and
chiller.
•
In some countries, it is forbidden to run electrical cables and water pipes in the same conduit.
In this case, two separate conduits are required. But then a problem arises at the level of the
Innova LC Positioner entrance.
•
Depending on the method used, one of the two options shown hereafter (IllustrationsIllustration
3-7 and Illustration 3-8) must be used.
Innova 2100-IQ, 3100/3100-IQ, 4100/4100-IQ Cardiovascular Imaging System Pre-Installation Manual
GE Healthcare Direction 5160944-13-1EN, Revision 2
Chapter 3 Physical Requirements of Room 71
