GE LOGIQ V2 User Guide

Measurement and Analysis
LOGIQ V2/LOGIQ V1 – User Guide 2-69
Direction 5610736-100 Rev. 9
Basic Measurements (continued)
Table 2-7: System Measurements and Accuracies
Measurement Units Useful Range Accuracy Limitations or Conditions
Depth mm Full Screen <=10% NA
Angle degree Full Screen <=5% NA
Distance:
Axial mm Full Screen <5% Linear Probes, Convex
Probes, Sector Probes
Lateral mm Full Screen <5% Linear Probes, Convex
Probes, Sector Probes
Circumference:
Trace mm Full Screen <=10% Linear Probes, Convex
Probes, Sector Probes
Ellipse mm Full Screen <=5% Linear Probes, Convex
Probes, Sector Probes
Area:
Trace
mm
2
Full Screen <=5% Linear Probes, Convex
Probes, Sector Probes
Ellipse
mm
2
Full Screen <=5% Linear Probes, Convex
Probes, Sector Probes
Time s Timeline Display <5% M mode, AM mode, CM mode,
PWD mode, CWD mode
Slope mm/s Timeline Display <=10% M mode, AM mode, CM mode,
Doppler SV
Position
mm Full Screen <=2 mm PWD mode
Doppler Velocity cm/s Form 0 to 100 cm/s
From 100 to 130 cm/s
<15%
<10%
PWD mode, CWD mode
Doppler Angle
Correction
cm/s From 0-80° <=5% PWD mode
