GE VAT2000 User Manual

6. Control Functions and Parameter Settings
6-42
B11-0~7
Program frequency (speed) setting
B11-8
Selection mode setting
Up to eight fixed output frequencies or speed are allowed when PROG function is enabled.
Set desired frequencies or speed to parameters B11-0 to B11-7, in percentage of maximum
output (B00-4) and (B01-4).
Selection of speeds or frequencies are done through auxiliary functions S0, S1, S2, S3, and
SE, as shown in below table.
(1) For binary selection mode (B11-8=1) (1) For direct selection mode (B11-8=2)
Sequence command
SE S3 S2 S1 S0
Selected
frequency
OFF OFF OFF B11-0
OFF OFF
ON
B11-1
OFF
ON
OFF B11-2
OFF
ON ON
B11-3
ON
OFF OFF B11-4
ON
OFF
ON
B11-5
ON ON
OFF B11-6
**
ON ON ON
B11-7
*
: SE and S3 are not used.
B11-1
(A00-2)
A00-0
(A00-2)
A00-0
B11-0
(C04-4) PROG
(C04-6) S0
Binary mode
B11-8=1
Bynary mode
B11-8=2
(C04-6) S0
(C04-7) S1
(C04-7) S1
(C04-9) S3
(C04-8) S2
(C04-8) S2
(C05-0) SE
Output frequency (Speed)
B11-2
B11-3
B11-4
B11-5
B11-6
B11-7
B11-6
Time
Program run example
(When command RUN is ON)
Set the PROG command input terminal with C04-4. Set the S0, S1, S2, S3 and SE input
terminals with C04-6~C05-0.
Sequence command
SE S3 S2 S1 S0
Selected
frequency
OFF OFF OFF OFF OFF Latest
value
OFF OFF OFF OFF
ON
B11-0
OFF OFF OFF
ON
OFF B11-1
OFF OFF
ON
OFF OFF B11-2
OFF
ON
OFF OFF OFF B11-3
ON
OFF OFF OFF OFF Latest
value
ON
OFF OFF OFF
ON
B11-4
ON
OFF OFF
ON
OFF B11-5
ON
OFF
ON
OFF OFF B11-6
ON ON
OFF OFF OFF B11-7
When S0 to S3 are all OFF the latest frequency
set value is hold. After power ON the latest
value is cleared to “0”
