GE VAT2000 User Manual

3. Test Operation and Adjustment
3-3
3-3 Flow of Test Operation
Start
↓
Installation and wiring
↓
Initial power supply
↓
Setting of rated items
↓
Automatic Tuning
↓
Test operation with
operation panel
↓
Setting of parameters
compatible with
external control
↓
Test operation includin
g
external control
↓
End of test operation
Fig. 3.1 Test operation procedure
CAUTION
1. Check that the wiring is correct.
2. The power supply must always be kept in the tolerable range.
3. Always check that the inverter rating and motor rating match.
4. Always correctly install the front cover before turning the power on.
5. Assign one worker to operate the switches, etc.
6. Refer to the Chapter 6 and observe the precautions when changing the set values such as torque
boost A02-0.
Refer to part 3-4 to 3-6
Refer to part 3-6
Refer to Chapter 5, and perform test operation with
the control input/output from the terminal block.
