7. Options
7-2
Table 7-1 (continued)
Plug-in PCB options
Item Type
&
Manual
Function
Option
class
Speed detection
1 (complimentary
compatible)
U2KV23DN1
(PCST-3229)
This is a speed detection PCB for the IM vector control
with speed sensor, and is compatible with the
complimentary output type encoder.
Response frequency: Change between 60±10kHz and
20kHz.
I
Speed detection
2 (line driver
compatible)
U2KV23DN2
(PCST-3300)
This is a speed detection PCB for the IM vector control
with speed sensor, and is compatible with the line
driver output type encoder.
Response frequency: 250kHz (signal: A, B, Z phase)
I
Speed detection
3 (PM
compatible)
U2KV23DN3
(PCST-3301)
This is a speed detection PCB for the PM drive
control, and is compatible with the line driver output
type encoder.
Response frequency: 250kHz (signal: A, B, Z, U, V, W
phase)
I
Relay interface U2KV23RY0
(PCST-3302)
This is used to expand the contact input/output points.
Relay input : 4 points (PSI6 to 9)
1c contact output : 2 points (PSO4, 5)
III
PC interface U2KV23PI0
(PCST-3303)
This is used to receive parallel settings from the PLC.
Parallel data input : 16 bits
Data length : 16, 12, 8 bits selective
Format : Binary or BCD selective
Open collector output: 2 points (PSO4, 5)
III
Serial interface U2KV23SL0
(PCST-3304)
This is used to make a connection with serial
transmission to the personal computer, etc.
Transmission : RS-232C, RS-422/485Multi-
drop is possible for up to 32
units.
Baud rate : 1200~9600 bps
III
Profibus interface U2KV23SL6
(PCST-3307)
This is used to make a connection with the network on
the Profibus DP communication protocol.
Baud rate : 12Mbps
No. of stations : 126 stations
III
Analog interface
(*)
U2KV23AD0
(PCST-3264)
This is used to give the analog setting input a higher
precision.
Analog input : 3 points (insulated: signed 15 bits)
II
Trace back
interface
(*)
U2KV23TR0
(PCST-3265)
This is used to analyse a fault by saving, replaying and
analysing the various data such as the current at the
time of the fault.
Analog output : 2 points (insulated: signed 11 bits)
II
The above Optional PCBs must be installed by the user. Please ask your supplier for dedicated instruction
manuals.
(*) Future development
