GE VAT2000 User Manual

Appendix
A-1
Appendix 1 Type Description System


Standard specifications


200V Series
Item Specifications
System 200V Series (NxxKx)
Type (VAT2000-U2KN_) 00K4 00K7 01P5 02P2 04K0 05K5 07K5 11K0 15K0 18K5 22K0 30K0 37K0
Rated capacity
[kVA]
(Note 1)
1.0 1.7 2.7 3.8 5.5 8.3 11.4 15.9 21.1 26.3 31.8 41.0 50.0
Max. continuous
rated current
[A]
(Note 2)
3.05.08.01116243346617692118144
Max. applicable
motor
[kW]
(Note 3)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
Working ambient
temperature
−
10 to 50°C
Carrier frequency
(Note 5)
Standard 10kHz, variable between 1 and 15kHz
Standard
4kHz,
variable
between 1
and 15kHz
Constant torque
(Note 8)
Overload current
rating
150% for 1min.
Rated capacity
[kVA]
(Note 1)
1.2 2.1 3.0 5.1 7.6 10.0 14.5 19.3 24.2 29.7 37.4 45.0 55.0
Max. continuous
rated current
[A]
(Note 2)
5.0 8.0 11 16 22 33 42 61 76 86 108 134 161
Max. applicable
motor
[kW]
(Note 3)
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45
Working ambient
temperature
−
10 to 40°C
(Note 4)
−
10 to 50°C
Carrier frequency
(Note 5)
Standard 4kHz, variable between 1 and 15kHz
Inverter ratin
g
Variable torque
Overload current
rating
120% for 1min.
Power
supply
Rated input AC
voltage: rated
input frequency
200~230V
±
10%
50/60Hz
±
5%
200~220V
±
10%/50Hz
±
5%
200~230V
±
10%/60Hz
±
5%
Rated output
voltage
200~230V (Max.)
(Note 7)
Output
(Note
9)
Output frequency 0.1~440Hz
Structure Wall-mounted
Enclosure IP20 IP00
Approx. weight
(kg)
3.5 6 13 26 55 60
Cooling method Self-cooling Forced air cooling
Const-
ruction
Paint color Munsell N4.0
Working environment
Indoors, Relative humidity: 95%RH or below (no dew condensation), Altitude: 1000m or less,
Vibration: 3.0m/s
2
or less
Freedom from corrosive or explosive gases, steam, dust, oil mist or cotton lint.
