6. Control Functions and Parameter Settings
6-58
C00-5
Control source switchover method (J1 setting)
J1 setting =1: OFF =2: ON
Select whether to use the terminal block input signals with the local operation mode.
Refer to section 5-5 for details.
C00-6
Control source switchover method (J2 setting)
J2 setting =1: OFF =2: ON
Select the auxiliary command input when the COP command is ON.
Refer to section 5-5 for details.
C02-0~8
Various setting input selection
Refer to section 5-9 for details.
C03-0~7
Sequence input terminal function
−
1
C04-0~9
Sequence input terminal function
−
2
C05-0~9
Sequence input terminal function
−
3
C06-0~8
Sequence input terminal function
−
4
Refer to section 5-3, 5-6 for details. Refer to the explanation for B06-0 to 6 (ratio interlock
bias increase /decrease function) for details on C03-7 and C05-3 to 4.
C07-0~9
Analog input terminal function
Refer to section 5-7 for details.
