6. Control Functions and Parameter Settings
6-7
6-3 Block-B parameters
The Block-B parameters are divided into the basic functions, extended functions and software option
functions.
Block-B parameters (Basic function of V/f control) list
ApplicationNo. Parameter Unit Default Min. Max. Function
ST V/f VEC PM
B00 – Output rating
0 Rated input voltage
setting
7. 1. 7. Select the rated input voltage from the
following table.
When this data is changed, the
output voltage data will be changed
to the same value.
1 Max./base frequency
simple setting
1. 0 9 Select the output frequency rating
from the combination below.
2 Motor rated output kW Inverter
rating
0.10 500.00 Motor rated power at the base speed.
3 Rated output voltage V 200
/400.
39. 480. This is the rated motor voltage, which
can not be set to a larger value than the
input voltage set in B00-0.
The Automatic Voltage regulator DC-
AVR does not operate when is set to 39.
(then the output voltage equals the input
voltage at the base frequency.)
4 Max. frequency Hz 50.0 3.0 440.0
5 Base frequency Hz 50.0 1.0 440.0
When "B00-1" is a value other than 0,
these values will be rewritten with the
data set in B00-1
6 Motor rated current A Inverter
rating
Inverter
rating
× 0.3
Inverter
rating
The overcurrent limit, OLT, current %
display and meter output. are related
to this setting
7 Carrier frequency 17.0 1.0 21.0 The noise can be lowered by
changing the PWM carrier frequency
and control method, which affects to
the sound generated from the motor.
This can be changed while running.
1.0 to 15.0:
Monotone sound
method (Carrier frequency: 1.0 to
15.0kHz)
15.1 to 18.0:
Soft sound method 1
(Basic carrier frequency: 2.1 to
5.0kHz)
18.1 to 21.0:
Soft sound method 2
(Basic carrier frequency: 2.1 to
5.0kHz)
Value
200V
System
400V
System
1 200V 380V
2 200V 400V
3 200V 415V
4 220V 440V
5 220V 460V
6 220V 480V
7 230V 400V
Value Ftrq (Hz) Fmax (Hz)
0 Free setting on B00-4 and B00-5
150 50
260 60
360
475
5
50
100
670
780
890
9
60
120
