7. Options
7-9
7-5 Electro Magnetic Compliance, EMC
Electromagnetic Compliance with the EN50081 & EN50082 is achieved by using appropriate EMC filters.
EMC foot print filters can be mounted on the drive’s foot saving space in cabinets, or alternatively along
side the drive when the total depth is a problem.
Details of Foot print and Stand alone filters are given below.
(1) Foot-print filters
EMC Filter Applied Inverter ratings Current Dimensions
Part No C/T V/T L x W x H X x Y Ho. M Term.
U2KF3016MD1 U2KN00K4 U2KN00K4 16A 288x175x51 273x100 M5 10mm2
U2KN00K7 U2KN00K7
U2KN01K5 U2KN01K5
U2KX00K4 U2KX00K4
U2KX00K7 U2KX00K7
U2KX01K5 U2KX01K5
U2KX02K2 U2KX02K2
U2KX04K0 U2KX04K0
U2KF3030MD1 U2KN02K2 U2KN02K2 30A 288x175x51 273x100 M5 10mm2
U2KN04K0 U2KN04K0
U2KF3032MD2 U2KX05K5 U2KX05K5 32A 320x221x51 305x150 M5 10mm2
U2KX07K5 U2KX07K5
U2KF3058MD3 U2KX11K0 U2KX11K0 58A 427x275x66 402x225 M5 10mm2
U2KX15K0 U2KX15K0
U2KX18K5 U2KX18K5
U2KF3060MD2 U2KN05K5 U2KN05K5 60A 230x221x51 305x150 M5 25mm2
U2KN07K5 U2KN07K5
U2KF3094MD3 U2KN11K0 U2KN11K0 94A 427x275x66 402x225 M5 35mm2
U2KN15K0 U2KN15K0
U2KF3096MD4 U2KX22K0 U2KX22K0 96A 575x312x67 549x200 M5 35mm2
U2KX30K0 U2KX30K0
(2) Stand Alone EMC filters
EMC Filter Applied Inverter ratings Current Dimensions
Part No C/T V/T L x W x H X x Y Ho. M Term.
PR3110STD U2KX37K0 - 110A 400x170x90 373x130 6.5 M6 50mm2
PR3120STD U2KN18K5 U2KN18K5 120A 400x170x90 373x130 6.5 M6 50mm2
U2KN22K0
PR3150STD U2KN30K0 U2KN22K0 150A 510x180x115 470x156 9.0 M8 95mm2
U2KX45K0 U2KN30K0
U2KX37K0
PR3180STD U2KN37K0 U2KN37K0 180A 510x180x115 470x156 9.0 M8 95mm2
U2KX45K0
