GE VAT2000 User Manual

6. Control Functions and Parameter Settings
6-20
6-4 Block-C parameters
The Block-C parameters are divided into the basic functions, extended functions and hardware option
functions.
Block-C parameters (Basic function constants) list
ApplicationNo. Parameter Unit Default Min. Max. Function
ST V/f VEC PM
C00 – Control methods
0 Run command
method
1. 1. 3. Run command method is set.
= 1 : F·RUN, R·RUN
= 2 : RUN, REV
= 3 : Pulse (by Push-buttons)
(Pulse inputs for F·RUN and
R·RUN)

1 RUN/STOP methods 2. 1. 2. Set the stopping method for RUN
operation.
= 1 : Coast to stop
= 2 : Ramp down to stop

2 Jog stop method 2. 1. 2. Set the stopping method for JOG
operation.
= 1 : Coast to stop
= 2 : Ramp down to stop

3 Emergency stop
(EMS) input logic
1. 1. 2. Emergency stop input logic is set.
= 1 : Close to stop
= 2 : Open to stop

4 Emergency stop
(EMS) mode
1. 1. 3. Set the stopping method for the
emergency stop.
= 1 : Coast to stop without a fault
output
= 2 : Coast to stop with a fault
output
= 3 : Ramp down to stop

5 Control source
switchover method
(J1 setting)
1. 1. 2. Set whether to validate the remote
operation sequence for the local
operation mode. Fig 5.2
= 1 : Disables = 2 : Enables

6 Control source
switchover method
(J2 setting)
1. 1. 2. Select the No. of auxiliary operation
sequence input points when the COP
command is ON. Fig 5.2
= 1 : Terminal block input
= 2 : Serial input

7 Run contact output
condition selection
1. 1. 2. The conditions for turning the
sequence RUN output ON are set.
= 1 : ON at pre-excitation
= 2 : OFF at pre-excitation

C01 – Start/stop frequency
0 Start frequency Hz 1.0 0.1 60.0

1 Stop frequency
(DC brake start)
Hz 1.0 0.1 60.0

