10 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.1 250 Output current A FLOAT 16/32 0.0 0.0 0.0 R FVS
The drive output current is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.2 252 Output voltage V FLOAT 16/32 0.0 0.0 0.0 R FVS
The drive line voltage output is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.3 254 Output frequency Hz FLOAT 16/32 0 0 0 R FVS
The drive output frequency is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.4 256 Output power kW FLOAT 16/32 0.0 0.0 0.0 R FVS
Displays the drive output power.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.5 288 Output cosphi FLOAT 0.0 0.0 0.0 ER FVS
The cosphi value (for Asynchronous motor) is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.6 3394 Output active curr A FLOAT 0.0 0.0 0.0 ER FVS
It is the active component (corresponding to the active electric power to the motor terminals) of the output cur-
rent. It corresponds to the absolute value of the torque current.
When the value is positive means that the motor is absorbing power from the drive (to develop motor torque).
When the value is negative means that the motor is operating as a generator, that provides power to the drive
(the motor is developing braking torque).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.7 628 Ramp setpoint FF INT16 16/32 0 0 0 R FVS
The ramp reference is displayed. This is the speed value the drive must reach at the end of the ramp.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.8 664 Speed setpoint FF INT16 16/32 0 0 0 R FVS
The speed reference is displayed. This is the value measured at the output of the speed reference circuit.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.9 260 Motor speed FF INT16 16/32 0 0 0 R FVS
The actual output speed of the motor is displayed (in Flux vector CL = speed measured by the encoder, in Flux
vector OL / V/f control = speed estimated by the drive).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.10 270 DC link voltage V FLOAT 16/32 0.0 0.0 0.0 ER FVS
The direct voltage of the intermediate circuit capacitors is displayed (DC-Bus).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.11 272 Heatsink temperature degC INT16 16 0 0 0 ER FVS
The temperature measured on the drive heatsink is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.12 290 Motor temperature degC FLOAT 16 0.0 0.0 0.0 ER FVS
Displays motor temperature in °C based on type of sensor selected to manage the alarm.
Equals 0 when direct conversion from count/ohm to °C is not possible, for example with PTC sensors.
