Remove the two screws ( ).
Remove the taillight lens ( ).
Slightly press the bulb ( ) and turn it
counterclockwise.
Install a new bulb in the reverse order of
removal.
2.
1.
(3)
(1)
(2)
3.
4.
1
2
3
(1) Screws
(2) Taillight lens
(3) Bulb
Brake/Tail Light Bulb
95
10/03/11 17:16:42 32KRHA00_105

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda XR125L and is the answer not in the manual?

Honda XR125L Specifications

General IconGeneral
Compression Ratio9.2:1
Transmission5-speed
Fuel SystemCarburetor
Front SuspensionTelescopic fork
Front BrakeSingle disc
Rear BrakeDrum
Front Tire90/90-19
Rear Tire110/90-17
IgnitionCDI
Final DriveChain
Engine TypeAir-cooled 4-stroke single-cylinder OHC
Bore x Stroke56.5 mm x 49.5 mm
Rear SuspensionSwingarm with single shock
Fuel Capacity12 L
Max. Torque10.4 Nm @ 6, 500 rpm
