Refer to the Safety Precautions on page .

Check the chain slider for wear. When the

thickness of the chain slider reaches the

limit, the chain slider must be replaced. See

your Honda dealer. Chain slider thickness

limit:

(1)

(1) Chain slider

DRIVE CHAIN SLIDER

1.0 mm (0.04 in)

10/03/11 17:14:41 32KRHA00_087

Questions and Answers:

Need help?

Do you have a question about the Honda XR125L and is the answer not in the manual?

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
