Honda XR125L User Manual

Refer to the Safety Precautions on page .
Servicemorefrequentlywhenriddeninrain,
at full throttle, or when deposits can be seen
in the transparent section of the drain tube.
Remove the crankcase breather tube plug
( ) from the tube and drain deposits into
a suitable container.
Reinstall the crankcase breather tube
plug.
(1)
1.
2.
53
1
(1) Crankcase breather tube plug
CRANKCASE BREATHER
62
10/03/11 17:12:50 32KRHA00_072

Honda XR125L Specifications

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
