Honda XR125L User Manual

−−
−
Normal Air Temperature
10° 35°C (50° 95°F)
Before starting, insert the key, turn the
ignition switch ON and confirm the
following:
The engine stop switch is at (RUN).
The fuel valve is ON.
The transmission is in neutral
(neutral indicator is ON).
Pull the choke lever ( ) up all the way to
Fully ON ( ).
With the throttle 1/8 1/4, press the
start button.
Start the engine.
Immediately after the engine starts, push
the choke lever ( ) down to the Halfway
Position ( ).
Warm up the engine by opening and
closing the throttle slightly.
About a half minute after the engine
starts, push the choke lever ( ) down all
the way to Fully OFF ( ).
If idling is unstable, open the throttle
slightly.
1.
2.
3.
4.
5.
B
C
A
1
1
1
Preparation Starting Procedure
42
10/03/11 17:10:37 32KRHA00_052

Honda XR125L Specifications

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
