Honda XR125L User Manual

Installation:
The seat must be removed for air cleaner
maintenance and to access the owner’s
manual.
Slide the seat ( ) back.
Remove the bolts ( ) and collars ( ).
Remove the right and left side covers
(page ).
Removal:
Align the front recesses ( ) to the front
hooks ( ) of the frame cross member,
and rear recess ( ) to the rear hook ( ).
Slide the seat into position.
Install the collars and tighten the bolts.
Install the both side covers.
1.
2.
3.
4.
1.
2.
3.
12
3
4
5
67
(3)
(5)
(2)
(1)
(6)
(2)35
(7)
(4)
(1)
(1) Bolts
(2) Collars
(3) Seat
(4) Front recesses
(5) Front hooks
(6) Rear recess
(7) Rear hook
SEAT
36
10/03/11 17:10:02 32KRHA00_046

Honda XR125L Specifications

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
