The document bag (1) is put into the
document compartment (2) under the seat
(page ).
This owner’s manual and other documents
should be stored in the document bag.
When washing your motorcycle, be careful
not to flood this area with water.
(2)
(1)
36
(1) Document bag
(2) Document compartment
DOCUMENT COMPARTMENT
37
10/03/11 17:10:06 32KRHA00_047

Honda XR125L Specifications

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
