Lubricate every 1,000 km (600 miles) or
sooner if chain appears dry.
The drive chain on this motorcycle is
equipped with small O-rings between the
link plates. These O-rings retain grease
inside the chain to improve its service life.
The O-rings in this chain can be damaged
by steam cleaning, high pressure washers,
and certain solvents. Clean the side surfaces
of the chain with a dry cloth. Do not brush
the rubber O-rings. Brushing will damage
them. Wipe dry and lubricate only with SAE
80 or 90 gear oil. Commercial chain lubri-
cants may contain solvents which could
damage the rubber O-rings.
Lubrication and Cleaning:
Replacement drive chain:
76
CHOHO 428HO 132LE
10/03/11 17:14:35 32KRHA00_086

Honda XR125L Specifications

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
