Honda XR125L User Manual

−−
Refer to the Safety Precautions on page .
Check for smooth rotation of the throttle
grip from the fully open to the fully
closed position at both full steering
positions.
Measurethethrottlegripfreeplayatthe
throttle grip flange.
Thestandardfreeplayshouldbe
approximately:
To adjust the freeplay, loosen the lock nut
( )andturntheadjuster( ).
1.
2.
1
(1)
(2)
53
2
(1) Lock nut (2) Adjuster
THROTTLE OPERATION
70
26mm(0.080.24in)
10/03/11 17:13:52 32KRHA00_080

Honda XR125L Specifications

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
