Honda XR125L User Manual

Park the motorcycle on firm, level ground to
prevent it from falling over.
Ifyoumustparkonaslightincline,aimthe
front of the motorcycle uphill to reduce the
possibility of rolling off the side stand or
overturning.
After stopping the motorcycle, shift the
transmission into neutral, turn the fuel
valve OFF, turn the handlebar fully to the
left, turn the ignition switch OFF and
remove the key.
Use the side stand to support the
motorcycle while parked.
Lock the steering to help prevent theft
(page ).
1.
2.
3.
33
PARKING
49
10/03/11 17:11:13 32KRHA00_059

Honda XR125L Specifications

General

Compression Ratio	9.2:1
Transmission	5-speed
Fuel System	Carburetor
Front Suspension	Telescopic fork
Front Brake	Single disc
Rear Brake	Drum
Front Tire	90/90-19
Rear Tire	110/90-17
Ignition	CDI
Final Drive	Chain
Engine Type	Air-cooled 4-stroke single-cylinder OHC
Bore x Stroke	56.5 mm x 49.5 mm
Rear Suspension	Swingarm with single shock
Fuel Capacity	12 L
Max. Torque	10.4 Nm @ 6, 500 rpm
