Refer to the Safety Precautions on page .
Check the fork assembly by locking the
front brake and pumping the fork up and
down vigorously. Suspension action
should be smooth and there must be no
oil leakage.
Carefully inspect all front and rear
suspension fasteners for tightness.
Swingarm bearings should be checked by
pushing hard against the side of the rear
wheel while the motorcycle is on a
support block. Freeplay indicates worn
bearings.
3.
2.
1.
53
FRONT AND REAR SUSPENSION
INSPECTION
78
10/03/11 17:14:46 32KRHA00_088

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda XR125L and is the answer not in the manual?

Honda XR125L Specifications

General IconGeneral
Compression Ratio9.2:1
Transmission5-speed
Fuel SystemCarburetor
Front SuspensionTelescopic fork
Front BrakeSingle disc
Rear BrakeDrum
Front Tire90/90-19
Rear Tire110/90-17
IgnitionCDI
Final DriveChain
Engine TypeAir-cooled 4-stroke single-cylinder OHC
Bore x Stroke56.5 mm x 49.5 mm
Rear SuspensionSwingarm with single shock
Fuel Capacity12 L
Max. Torque10.4 Nm @ 6, 500 rpm
