HP StorageWorks 8/20q User Manual

HP StorageWorks 8/20q and SN6000 Fibre Channel Switch Enterprise Fabric Management Suite User Guide 109
SNMP v3 security
Simple Network Management Protocol Version 3 (SNMPv3) is an interoperable standards-based protocol
for network management. SNMPv3 provides secure access to devices using a combination of
authenticating and encrypting packets over the network. SNMP v3 security is an additional layer of
security. The SNMP v3 security is available on a secure (SSL) entry switch. The security features provided in
SNMPv3 are:
• Message integrity—Ensuring that a packet has not been tampered with during transit
• Authentication—Determining that the message is from a valid source
• Encryption—Scrambling the contents of a packet to prevent it from being seen by an unauthorized
source
You configure SNMP v3 security in the SNMP v3 Manager dialog box (Figure 61).
Figure 61 SNMP v3 Manager dialog box
Trap Version Specifies the SNMP version (1 or 2) with which to format traps.
Trap 1 Enabled Enables or disables the trap. if disabled, traps are not sent to trap
monitoring stations and the trap settings are not configurable.
Trap Address Specifies the IP address to which SNMP traps are sent. A maximum of 5
trap addresses are supported. The default address for trap 1 is
10.0.0.254. The default address for traps 2–5 is 0.0.0.0.
Trap Community Trap community password (up to 32 characters) that authorizes an SNMP
agent to receive traps. This is a write-only field. The value on the switch
and the SNMP management server must be the same. The default is
public.
Trap Severity Specifies a severity level to assign to the trap. Open the drop-down list
and choose a level. The Trap 1 Enabled option on the SNMP Properties
dialog box must be enabled to access this drop-down list. Trap severity
levels include Unknown, Emergency, Alert, Critical, Error, Warning,
Notify, Info, Debug, and Mark
Trap Port Specifies the port number (between 1–65535) on which a trap is set. The
default is 162.
Table 19 SNMP Properties dialog box fields (continued)
Field Description
