HP StorageWorks 8/20q User Manual

128 Managing Ports
Media—Transceiver specifications and vendor information (Table 28)
DDM—Digital Diagnostics Monitoring (DDM); transceiver temperature, voltage, current,
and power values (Table 29)
Table 25 Port Information data window—Summary
Fields Description
Port Address Port Fibre Channel address
Administrative Port Type Administrative port type (G, GL, F, FL, TR, or Donor). This value is
persistent; it is maintained during a switch reset. During port
auto-configuration, it is used to determine which operational port states
are allowed.
Operational Port Type Port type that is currently active. This value is set during port
auto-configuration based on the administrative port type.
Administrative Port State Port state (Online, Offline, Diagnostics, or Down) that has been set by the
user. This state may be different from the configured administrative state if
the user has not saved it in the switch configuration. Use this state to try to
set the port operational state. This value is not persistent and is lost after a
switch reset.
Operational Port State Port state that is currently active. This value may be different from the
administrative port state; for example, due to the presence of an error
condition.
Configured Administrative
Port State
Port state (Online, Offline, Diagnostics, or Down) that is saved in the
switch configuration, either by the user or at the factory. This value is
persistent; it is maintained during a switch reset, and is used after a reset
to set the port operational state.
Logged In Indicates whether the device connected to the port is logged in or not
Port Connection Status E_Port connection status. Status can be None, Connecting, Connected or
Isolated.
Reason for Status Reason why E_Port is isolated
Administrative Port Speed Port speed requested by the user
Operational Port Speed Speed actually being used by the port
Port Speed Supported Speeds supported by the port (1-Gb/s, 2-Gb/s, 4-Gb/s, 8-Gb/s,
10-Gb/s and 20-Gb/s)
Symbolic Name User-defined name for a port
Port WWN Port World Wide Name
POST Status Status from the most recent Power On Self Test
POST Fault Code Fault code from the most recent Power On Self Test
Test Status Status from the most recent port test
Test Fault Code Fault code from the most recent port test
Table 24 Port Information data window buttons (continued)
Button Description
