Table 26 Port Information data window—Advanced
Field Description
MFS Mode Multiple Frame Sequence bundling status
Configured I/O Stream
Guard
Configured RSCN message suppression status. If supported, status can be
enabled, disabled, or automatically determined by the switch.
Operational I/O Stream
Guard
The actual RSCN message suppression status. If supported, status can be
enabled, disabled, or automatically determined by the switch.
Device Scan Device scan status. Enabled means the switch queries the connected device
during login for FC-4 descriptor information.
Auto Performance
Tuning
Enables the switch to dynamically control the MFS_Enable, VI_Enable and
LCF_Enable features based on the operational state of the port
AL Fairness Controls how frequently the switch can arbitrate for access. Affects only ports
running in loop (FL) mode.
Port Binding Ties a specific device WWN to a physical port number
Upstream ISL ISL over which the switch sends requests intended for the principal switch
Downstream ISL ISL over which the switch receives requests intended for the principal switch
Remote Switch WWN Displays WWN, if known, of the isolated switch attempting a connection on
that port
Table 27 Port Information data window—Extended Credits
Field Description
Extended Credits
Requested
Number of credits requested by other ports
Max Credits Available Maximum number of credits granted to a port that can be used when
extending port credits
Credits to Donate Number of credits available to be donated by the selected port
Donor Group Donor group of the selected port
Valid Donor Groups Number of separate groups within which extended credits may be donated
and assigned
Table 28 Port Information data window—Media
Field Description
Media Type Transceiver fibre type, such as single mode, multi-mode, or copper
Media Speed Maximum transceiver speed
Media Transceiver type
Media Transmitter Transceiver transmitter type, such as longwave, shortwave, or electrical
Media Distance Maximum transceiver transmission distance
Media Vendor Company that manufactured the SFP
Media Vendor ID IEEE registered company identification number
Media Part Number Part number assigned to the SFP
Media Revision Transceiver hardware version
