HP StorageWorks 8/20q and SN6000 Fibre Channel Switch Enterprise Fabric Management Suite User Guide 39
Devices data window
The Devices data window (Figure 19) displays information about name server devices and proxied devices
(from configuration of TR ports) connected to the switch. To display the Devices data window, click the
Devices tab below the data window.
Figure 19 Devices data window
Because remote devices are proxied, the following limitations in available information exist:
• The Details button is disabled.
• The Target/Initiator field always reads Unknown.
• The Vendor field text is decoded from the OUI in the Port WWN, rather than potentially being read
from the FC4Descriptors, as is the case with local devices.
• The proxied devices are indicated in the Device data window by italic text and the notation "(TR)" after
the port number.
• Proxied devices are also unavailable in the Active Zoneset data window. For more information, see
”Viewing active and configured zone set information” (page 51).
The Devices data window fields are described in Table 7.
Table 7 Devices data window fields
Field Description
Port WWN Port World Wide Name
Nickname Device port nickname. To create a new nickname or edit an existing
nickname, double-click the cell and enter a nickname in the Edit
Nickname dialog box. For more information, see ”Managing device port
nicknames” (page 40).
Details Click (i) to display additional information about the device (Figure 20).
FC Address Fibre Channel address
Switch Switch name
Port Switch port number
Target/Initiator Device type: Target, Initiator, or Both
Vendor Host Bus Adapter/Device Vendor
