Connect for Communication
4
156 809480 Instruction Manual XPR300
Table 26 – Pinout for J19 on the discrete cable
1 Inputs are optically isolated. They require 24 VDC at 12.5 mA or dry-contact closure at 8 mA.
2 Outputs are optically isolated, open-collector transistors. The maximum rating is 24 VDC at 10 mA.
3 Although the plasma power supply has output capability, it is normally used solely as an input.
4 CNC +24 VDC provides 24 VDC at 200 mA maximum. A jumper is required on J17 to use 24 V power.
5 Shield ohmic contact is used to interface to plasma interface boards that have their own ohmic contact
circuit. Refer to How to use ohmic contact sense on page 193.
End A (Figure 42 on
page 154)
J19 pin
Input/
Output
Signal Function Wire color
1
Output
2
Error + Notifies the CNC that an alert, error, or failure has
occurred. This signal is not intended to be used to
stop table motion.
Orange
2 Error - Black
3
Output
2
Ready for start +
Notifies the CNC that the plasma power supply is
ready for the plasma start.
White
4 Ready for start - Red
5
Output
2
Auto pierce detect + Notifies the CNC that the plasma power supply has
detected that the system has pierced through the
workpiece and is ready to begin motion.
Green
6 Auto pierce detect - Red
7
Output
5
Shield ohmic
contact +
Refer to notes below for further info.
Blue
8
Shield ohmic
contact -
Red

Hypertherm XPR300 Specifications

General

Cutting Current	300 A
Duty Cycle	100% at 300 A
Technology	X-Definition Plasma
Gas Supply	Oxygen, Nitrogen, Air
Cutting Capacity (Mild Steel)	38 mm (1.5 in)
Severance Capacity (Mild Steel)	75 mm (3 in)
Pierce Capacity (Mild Steel)	50 mm (2 in)
Input Voltage	200–480 V, 3-PH, 50/60 Hz
